With the development of oil and gas drilling industry,  people attach increasing importance to the solutions of Drilling Waste . Vertical Cuttings Dryer is one of the frequently-used equipment for the various special design for solutions of Drilling Waste. After the separation of Vertical Cuttings Dryer, the oil content of solid phase is less than 3%, which is 5% OOC.. Vertical Cuttings Dryer can be used for oil based drilling waste, water based drilling waste and composite based drilling waste.

The Screen Basket is mainly composed of upper flange, lower flange, reinforcing ribs, reinforcing rings, and stainless steel conical screen. The stainless steel conical screen is welded by several fan-shaped meshes. The fan-shaped screen of the Screen Basket is made of stainless steel wire rolled into special-shaped screen bars and support bars, which are welded and formed by special equipment, and the screen bars are arranged along the conical generatrix of the Screen Basket . In order to meet the requirements of different working conditions, the size of the screen gap of the ZH Screen Basket is 0.15 to 0.8 mm, and it can also be determined according to user requirements.

Since the Screen Basket is a high-speed rotating part during operation, and the drilling waste will fall on the Screen Basket from the hopper above the dryer, the high-speed rotation of the Screen Basket drives the high-speed rotation of the drilling waste, under the action of centrifugal force , liquids such as water and oil will be thrown out from the gap of the Screen Basket , and the solid phase will fall down under the action of gravity.

Under normal working conditions of Vertical Cuttings Dryer, the rotating speed of the rotating parts can be as high as 900 rpm. In this case, the anti-corrosion performance, wear-resistant performance of the material of the Screen Basket , the precision requirements of the gap, and the quality requirements of welding will be very high.

• ZH choose the high quality of stainless steel: SS304/SS316 for the Screen Basket of Vertical Cuttings Dryer increase the service life of the Screen Basket to a large extent, and the material cost, labor cost and time cost caused by the replacement of the Screen Basket are reduced. Simplify the operation and maintenance of the equipment Vertical Cuttings Dryer. It has been verified in many drilling worksite, and the service life of ZH’s Screen Basket is much higher than that of other brands.
• Highly precise stainless steel screen to ensure separation effect of Vertical Cuttings Dryer Drilling Waste Management.
• Different screen gap of the screen basket 0.15 to 0.8 mm for different work conditions. The gap, material of the Screen Basket can be manufactured by the custom request.
• ZH can manufacture the Screen Basket for different brands of Vertical Cuttings Dryer.
• ZH can manufacture the Screen Basket of Vertical Cuttings Dryer by the custom design.
